Applications
Be spliced with the tail of unused branches of fibre components to eliminate back reflection
Be used as a fibre end cap to prevent laser-induced damage
Characteristics
Precise geometry control
Use of glass with low hydroxyl content as cladding material
Use of UV-cured acrylate as coating material, which is easy to strip
Specifications
| Fibre type | CL 0/125-0/250 | CL 0/250-0/500 | CL 0/62.5-0/165 |
|---|---|---|---|
| Part No. | CL1010-A | CL1010-B | CL1010-C |
| Cladding diameter (μm) | 125.0±1.0 | 250.0±5.0 | 62.5±1.0 |
| Refractive index @1550 nm | 1.444 | 1.444 | 1.444 |
| Coating diameter (μm) | 245.0±10.0 | 500.0±15.0 | 165.0±5.0 |
| Proof test level (kpsi) | 100 | 100 | 100 |
